Tire Killer (Embedded Type) KT-DX19
Technical Parameters
Fixing Mode: Embedded
Panel Thickness: 10mm / 16mm / 20mm
Material: A3 Steel
Lifting Speed: 1S～2S
Rising Height of Tire Spikes: 120mm
Waterproof Grade: IP68
Working Temperature: -40℃～75℃
Control System: Electric
Voltage & Power: 220V / 150W
Surface Treatment: Plastic Spraying
Optional Colors: Yellow, Black, Red
Load Capacity: 50 Tons
Control Method: Control Box / Wireless Remote Control
Length: Customized according to on-site conditions
Linkage Function: Can be linked with barrier gate, traffic light, AB door, alarm system, etc.
Features
Installation: Surface-mounted, shallow-mounted
New structural design, sturdy and durable, high load-bearing capacity, compact structure with thick materials, greatly improving pressure resistance and tire puncture performance
Stable operation, low noise, suitable for various installation environments
Embedded type provides better stability after installation
Equipped with emergency anti-terrorism and fire linkage functions, vehicle detection protection including license plate recognition, infrared detection, radar, loop detector, realizing unmanned intelligent management
Manual lifting available in case of power failure
One-piece formed panel without welding, aesthetic, firm and pressure-resistant
Surface treated with high-grade anti-rust paint and equipped with engineering-grade reflective tape for appearance and warning
Configuration Options
Thickness: 16mm, 20mm, 25mm
