Electric Floor Spring KT-EDO004
Technical Parameters
Suitable Door Width: Within 200mm
Suitable Door Weight: Within 50KG
Opening Angle: Bidirectional 90°
Opening Direction: Bidirectional
Door Hold Time: Adjustable from 1–20 seconds
Opening Speed: Adjustable
Opening Buffer Distance: Adjustable
Closing Speed: Adjustable
Closing Buffer Distance: Adjustable
Remote Control Functions: Normally open, momentary, normally closed, automatic
Automatic Overload Protection: Obstacle rebound (overload)
Door Closing Position: External travel limit or automatic positioning
Left/Right Door Selection: Configurable
Power Supply: 110–250V
Input Power: Static 4W, max. 100W
Dual-Door Communication: Supported
Backup Power Supply: Optional
Max. Tensile Force: 120N
Shielding Signal Setting: Supported
Active Anti-Pinch: Safety beam or safety light curtain
Passive Anti-Pinch: Obstacle rebound function
Main Unit Dimensions: 171×211×37mm
Functions & Features
WIFI or 4G connectivity supported
Adjustable obstacle detection & rebound
Opening delay adjustment
Opening angle self-learning function
Delayed opening function
Remote door locking function
Dual door interlocking function
Master & slave door operation function
Opening & closing speed adjustable
Electric door lock compatible
Bluetooth adjustment supported
Secondary development supported
