7/14/11/22KW Reinforced Hydraulic Rising Bollard KT‑DX01
Technical Parameters
Material: Sheet metal + tempered glass
Installation: Wall-mounted / Floor-mounted (column optional)
Wiring mode: Bottom incoming & bottom outgoing
*Charging cable length: 5m (customizable)
Input voltage: AC 220V±15%
Input frequency: 50±10Hz
Rated power: 7KW / 11KW / 14KW / 22KW
Output voltage: AC 220V±15%
Max. output current: 32A*2
Metering accuracy: Class 1
Current limit protection: 1.1 times rated current
HMI: LCD display, LED indicators
Operation indication: Power, Charging, Fault
Charging mode: Auto full / Fixed power / Fixed amount / Fixed time
*Payment method: Card payment / QR code payment (optional)
Billing mode: Time-of-use billing
Communication interface: Ethernet / 4G (optional)
*Data openness: Support third-party platform access (optional)
*Expansion: Face recognition / License plate recognition / Parking lock / Parking radar (optional)
Executive standards: GB/T 20234, GB/T 18487, NB/T 33008, NB/T 33002
Management features: Power-off memory, adjustable rate, blacklist & whitelist, data communication, integrated one-card system
Safety functions: Over-voltage, under-voltage, overload, short-circuit, grounding, over-temperature, lightning protection, emergency stop, leakage protection
Application environment: Indoor / Outdoor
Operating temperature: -20℃～+70℃
Relative humidity: 5%～95% non-condensing
Protection class: IP54
Cooling mode: Natural cooling
Reliability (MTBF): ≥ 18000h
Optional items: All items marked with * are customizable.
Product Features
The product features a stylish and simple appearance, highly integrating AC charging interface, human-machine interaction interface, electrical safety design, control, metering and safety protection modules. Working with the on-board charger of electric vehicles, it provides multiple charging methods including card payment and mobile payment.
Equipped with three status indicators: power, charging and fault
Functions include emergency stop connection confirmation detection, charging door detection, charging gun lock, etc.
Easy operation: start charging by card swiping or QR code scanning
Charging modes: auto full charge / fixed power charge / fixed time charge / fixed amount charge
Multiple operation management modes: local settlement / platform operation
Payment methods: card payment, WeChat payment / Alipay payment
